Output Force: 8.5 Ton
Stroke: 50 mm
Battery Capacity: 70 cutting cycles
Max. Cutting Range: Ø50 mm (Copper, Aluminum and Armored cable)
Battery: 18V / 4.0Ah Li-ion
Charging Time: 2 hours
Battery Quantity: 2 pcs
Charger: 1 pc
Sealing Ring of Cylinder: 1 set
Weight (kg): 14.5
Packing Size (mm): 585 × 500 × 170
Characteristics:
Cuts armoured Al and Cu cables.
Special blades for cutting ACSR conductors are available on request.
●Closed cutting head with bolt interlock, rotatable, flip top style
●Two-stage hydraulic system features fast feed and power stroke upon reaching counter pressure, saving time.
●10000+ cycle service life.
●Press manual reset button to retract the ram when cutting is complete.
●Press manual reset button to retract the ram in case of error.
●Ram retracts to original position automatically when applied force exceeds rated capacity.
●Audible buzzer and red LED light in case of error.
●Quick motor stop for higher user safety.
●Powerful 18V Li-ion battery with low battery warning.
