Stone:
Dimension: Φ350 × Φ38 × 45 mm
Speed: 100–1500 rpm
Rotational Direction: Counter-Clockwise
Motor Power: 4.0 kW
Diameter: 160 mm (180 mm Optional)
Specimen Holder:
Maximum sample height: 40 mm
Force: 50–700 N
Speed: 10–125 rpm
Rotational Direction: Clockwise / Counterclockwise
Motor Power: 0.37 kW
Torque: 17 Nm
Removal Control:
Accuracy: 0.1 mm
Removal: 0.1–10 mm
Dresser:
Dresser Mode: Auto (Time, Removal) / Manual
Removal: 10–200 µm
Features：
Sample clamping and grinding system
1. The sample clamping disc and clamping head are positioned by ball bearings, and the pin spring is reset to achieve stable clamping of the sample disc. The installation operation is simple and convenient.
2. The installation screw of the grinding wheel disc is fixed, easy to disassemble and replace.
3. Sample quantitative grinding function, quickly and efficiently reaching the predetermined set amount, ensuring the consistency of sample grinding size.
Display system
1. Simple operation interface, easy to operate on the machine after simple training;
2. Three color light warning prompt, easy to find faults and save maintenance time.
Operating system
1. 10-inch LCD touch screen panel,real-time display of material grinding amount on the LCD screen, real-time dynamic equipment, simple and easy to understand interface, convenient and fast operation and setting;
2. Customize the program library to save and call program methods at any time, with simple and convenient operation.
Grinding wheel dress system
The grinding wheel dressing function can improve the grinding performance of the grinding wheel, ensure the flatness and sharpness of the grinding wheel, save time and cost to the maximum extent, and improve the efficiency of workpiece grinding.
Cleaning system
To improve the service life of the equipment, it is recommended to regularly maintain and keep the machine chamber clean. The plug-in flushing gun can quickly and conveniently clean the grinding area using circulating water.
Grinding stones
Different types of grinding stones are available for selection, in addition to alumina and silicon carbide grinding stones, diamond grinding discs are also provided to meet the rapid grinding needs of different materials.
