Technical data:
Stroke rate at no load (combined): 0 - 3.000 min-1
Pendulum cutting stages: 1 – 3
Stroke [mm]: 21
Setting wheel stroke rate selection combined: 1 - 6 Stufen
Max. cutting depth (wood) [mm]: 80
Max. cutting depth (aluminium) [mm]: 12
Max. cutting depth (metal) [mm]: 8
Cutting angle: left/right: 0°/15°/30°/45°
Electrical values:
Mains connection: 230 V, 50 Hz
Power input [W]: 850
Electric connection:
Connection plug: CEE 7/17
Cable length [m]: 3
Sound values according to EN 62841:
Sound pressure level [dB(A)]: 88
Sound power level [dB]: 99
Uncertainty K [dB]: 3
Vibration information according to EN 62841:
Vibration emission value jigsaw blade wood (ah) [m/s²]: 9.5
Uncertainty jigsaw blade wood (K) [m/s²]: 1.5
Vibration emission value jigsaw blade metal (ah) [m/s²]: 11.2
Uncertainty jigsaw blade metal (K) [m/s²]: 1.5
Safety feature:
Protection class: II
Dimensions:
Length (packaging excluded) [mm]: 280
Width (packaging excluded) [mm]: 75
Height (packaging excluded) [mm]: 180
Weight:
(packaging excluded) [kg]: 2
