Technical Specifications:
Current (ACA): 999.9 A: 40Hz~100Hz; ±(2.0%+5); 100Hz~1000Hz: ±(2.5%+5)
Current (DCA): 999.9 A; ±(2.0%+5)
Voltage (ACV): 999.9V/1500V; 40Hz~1000Hz: ±(1.0%+5)
Voltage (DCV): 999.9V/2500V; ±(1.0%+5)
Voltage (DC mV): 999.9 mV; ±(1.0%+5)
ACV(with LPF): 999.9V;: ±(2.0％＋9)
ACA(with LPF): 999.9A; ±(2.5％＋9)
ACA(with LPF): flex clamp sensor: 30.00A/300.0A/3000A; ±(4.0%+9)(center area)
ACA;with flex clamp sensor: 30.00A/300.0A/3000A; ±(3.0%+5) (center area)
Power (DC): 999.9 kVA/2500 kVA; ±(2.0%+20)
Frequency (A&V): 5.0 Hz to 999.9Hz; ±(0.5%+5)
Resistance (Ω): 999.9Ω/9.999KΩ/99.99kΩ; ±(1.0％+5）
Cpacitance（F）: 100.0μF/1000 μF; ±(1.0％+5）
Temperature: -40℃~400℃/-40℉~752℉;: ±(1.0%+30); ±(1.0%+60)
Features:
True RMS: √
Display count: 9999
Display: LCD: Dual display (V+A)
Jaw (Max conductor dia.): 35mm
Diode: √
Solar panel polarity indication: when <-10 DCV, Audible & Visual alarm
High voltage alarm: √
Over range indication: √
AUTO HOLD: √
Inrush current: √
PEAK: √
Bluetooth app: BT 5.0
Auto backlight: √
Low battery indication: √
Flexiable clamp compatible: UT-CS09D (optional)
IP rating: IP65
Overvoltage category: CAT III 1500V; CAT IV 600V
Certificates: CE, cETLus, RoHS
General Characteristics:
Power supply: 2 * AA
Product dimension: 295mm x 73mm x 50mm
Product color: Grey + Red
Accessories: test probe, temperature probe, batteries, manual
