VOLTAGE:
Input Voltage: 0-150V
Voltage Measurement Accuracy: 0.04%+1mV
Voltage (CV) Loading: Full range of voltages, user configurable resistance from 1mΩ upwards
CV Loading Accuracy: 0.04%+1mV
Sense Loading: Nominally 923kΩ, automatically included in all measurement results and all loading except open
CURRENT:
Current (CC) Accuracy: 0.05%+5µA
POWER:
Power (CW) Accuracy: 0.075%+25µW
RESISTANCE:
Resistive Loading: 42mΩ-900kΩ
Resistive (CR) Accuracy: 0.1%
Capacitive Loading: 0.3µF
LOADING MODES and TIMING:
Load Timing: Continuous, or 5µs to 10000s pulsed/stepped
Non-linear Loading Bandwidth: Typically >35kHz with ability to reduce bandwidth
Size: 5 inches high x 8.5 inches wide x 13 inches deep
Weight: Approximately 8 pounds (unpacked, without external power supply)
Power: External 12Vdc, 60VA power brick
Display: 5-inch diagonal, 800x480 pixel color LCD with touchscreenWarm Up Time: 20 seconds
Full Specifications: 15 minutes
Temperature:
Operating: 0 to +40°C, at 10 to 80% RH (non-condensing) Automatically reduces loading if overheating detected.
Storage: -20°C to +70°C, at 5 to 95% RH (non-condensing)
