Wekotec WEKO-TU Turbidity Analyzer (0/2/5/10/100NTU)

Measurement Range: Turbidity : 0 / 2 / 5 / 10 / 100NTU; Temperature : 0~60℃, 0~135℃

Resolution: 0.001NTU

Accuracy: ±2% at 0-40 NUT, and ±5% at 40-100 NTU

Repeatability: ±3% of F.S.

Calibration Method: Automatic Calibration, 2-point Calibration

Response time: 98% in 30seconds at 25℃

Temperature Compensation: 0 ~ 60℃

Ambient Temperature: -25 ~ 80℃

Analog Output: Two (2) DC 4~20mA, Isolated (measurement results & temperature, max. load 1000 Ω)

Digital OutputL RS232C, RS485

Cleaning Cycle: 0~24 hours

Power: 90~260VAC, 50/60Hz

Power Consumption: 30VA or lower

Protection: IP66

Dimensions (mm): 144 x 144 x 137

Detector: 90° transmitted light scattering type (continuity)
