The maximum length of ram: 300mm
Ram adjustment stroke: 300mm
Number of ram movement: 20/80n/min
Working desk size: 550×405mm
table travel(X,Y): 280×330mm
The distance between the axis of the tool bearing hole and the forearm of the column: 505mm
The distance between the end face of the cutter head support hole and the table: 540mm
X direction motor torque: 6(N/M)
Y direction motor torque: 6(N/M)
Fast-moving: 5X(m/min), 5Y(m/min)
Ball screw(X): FFZD3205-3/P4
Ball screw(Y): FFZD3205-3/P4
Main motor power: 3.7KW
Machine tool weight(about): 2800KW
package dimensions: 2300/2200/2300mm
