Worktable size: 1300×520mm
T-slot: 18×5×90mm
Max. loading of worktable: 600kg
Spindle center to column distance: 580mm
Spindle nose to table distance: 130-700mm
Rail type: Linear Guideway
Spindle taper: BT40
Spindle speed: 8000/12000rpm
Main motor power: 7.5/11kw
X axis travel: 650mm
Y axis travel: 500mm
Z axis travel: Z1:570, Z2:570mm
X/Y/Z rapid traverse: 30000mm/min
Max.weight of tool: 8*
Positioning accuracy: ±0.006mm
Re-positioning accuracy: ±0.003mm
Air pressure: 0.5-0.8mpa
Coolant: air conditioning
Overall dimension(LxWxH): 3250×2800×2950mm
Weight: 7500kg
