Power Supply: DC 9V Alkaline dry cell LR14 1.5V*6PCS, continues standby 300 hours
LCD Size: 124mm x 67mm (with backlight)
Data Storage: 2000 groups
Data Upload: RS232 interface
Automatic Shut Down
Automatically shut down after 15 minutes start up
Power Consumption
- Turn on the backlight： 45mA Max
- Turn off the backlight : 25mA Max
- Measurement: 100mA Max (Backlight shut off)
Working Temperature & Humidity: -10℃ ~ 40℃, below 80%RH
Storage temperature & humidity: -20℃ ~ 60℃, below 70%RH
Clamp Caliber: Φ68mm
Short-circuit Test Current: AC 20mA max
Open-circuit Test Voltage: AC 40V max
Test Voltage Wave: Sine wave
Electrode Distance Range: 1m ~ 100m
Line Voltage: Measurement below AC 600V
