Measuring range:
- SO2：0 ～ 100μL/L
- H2S：0 ～ 100μL/L
- CO: 0 ～ 1000μL/L
- HF: 0 ～ 10μL/L
Measuring accuracy:
- SO2：when the measured value ≤10μL/L， the error±0.2μL/L;
when the measured value≥10μL/L， the error≤±3%
- H2S：when the measured value≤10μL/L， the error±0.2μL/L;
when the measured value≥10μL/L， the error≤±3%
- CO: when the measured value≤50μL/L， the error±0.5μL/L;
when the measured value≥50μL/L， the error≤±4%
- HF: the error of measured value≤±0.1μL /L
Repeatablity:
- SO2：when the measured value≤10μL/L，the repeatablity≤±0.1;
when the measured value≥10μL/L,the repeatablity≤±2%
- H2S：when the measured value≤10μL/L,the repeatablity≤±0.1;
when the measured value≥10μL/L,the repeatablity≤±2%
- CO: when the measured value≤50μL/L,the repeatablity±0.3;
when the measured value≥50μL/L,the repeatablity≤±3%
- HF: the repeatability of measured value≤±0.1
Resolution: 0.1μL/L
Sampling flow: 0.2L/min
Measuring time: ≤180S
Working environment: Temperature-10℃ ～ +50℃,Humidity0 ～ 90%RH
Supply power: Lithium battery power supply, AC and DC dual-use, automatic switching, overcharge and over discharge protection function
Dimension: 330(mm)×220(mm)×150(mm)；
Weight: 4.8KG
Product features:
1. Long life detection components
2. Direct measurement without colorimetric tube or sensor
3. High accuracy and good repeatability
4. Built-in pressure regulator and electronic mass flow meter
5. Large color LCD display
6. Lithium battery power supply, AC and DC dual-use
7. The Sf6 Comprehensive Analyzer comes with cleaning function
