Test Stations: 3
Bending angle: (90±2)º
Bending speed: 5-150 cpm (adjustable)
Diameter of mandrel: 30mm
Width of clamp: 144mm
Dimensions: 860mmx460mmx800mm
Weight: 118kgs
Power Supply: AC 220V, 50Hz/60Hz
Product Description:
This Whole Sole Flexing Testing Machine is used to measure the flexing resistance of shoe soles under continuous movement. Before test, plunge some holes at the maximum bending position, and affix specimen at both, one fixed, one movable. Specimen runs flexing owing to the movement of machine. After a certain test cycles, discharge specimen and inspect how the specimen breaks.
Test Standards: ISO 17707, SATRA TM 161, EN 344, ISO 20344, DIN 53543
Product Features:
LED-SLD806 integrated display control box, menu operation mode
The position can be adjusted by jog, and the test speed can be adjusted
Mechanical parts are made of non-corrosive structural aluminum and stainless steel materials
Precision drive motor, stable operation and low noise
With counting and timing auto-stop function, the test can be automatically stopped by setting the test value
High-precision bearings are used for smooth and stable rotation and long active life
New vertical structure design, convenient sample installation
3 samples can be tested at the same time
Protective door can protect the hands of the operator, automatic stop when door opened
