Measuring Range (optional): -0.1~200MPa
Operating temp range: -20℃~75℃,≤85%RH
Accuracy: 0.1%FS; 0.25%FS; 0.5%FS
Storage Environment: -40℃~85℃,≤95%RH
Power Supply: Transducer: 5 ~10VDC
Transmitter: 9 ~36VDC
Limit Load: 150%
Output Signal:
+ Transducer: 1.5mV/V, 2mV/V,
+ Transmitter: 4-20mA, 0-20mA, 0-10V ,0-5V
Breaking load: 200%
Zero balance: 0.5%FS
Temp effect on output: 0.03%FS/℃
Full scale error: 1.0% FS
Long Stability: 0.2%FS/year
Compensated temp range: -10℃~60℃
Life: 700±5/350±5Ω
Process connection: M20×1.5, M12x1, M10 x1, 1/4NPT, G1/2, G1/4 or as custom
