Output sensitivity: 1.0-1.5mV/V
Material: Stainless steel
Non-linearity: ≤0.3%F.S.
Repeatability: ≤0.1%F.S.
Zero balance: ±2%F.S.
Operating temp range: -20~80°C
Compensated temp range: -10~60°C
Insulation resistance: ≥5000MΩ/100VDC
Recommended excitation voltage: 5-10VDC
Limit load: 150%F.S.
Cable size: φ3x3m
Protection class: IP64
Temp effect on output: ≤0.1%F.S./10°C
Temp effect on zero: ≤0.1%F.S./10°C
Cable Connection: Ex+: red; Ex-: black; Sig+: green; Sig-: white
