3rd Party Software Supported: X-Rite ColorCert, X-Rite Color iQC, X-Rite InkFormulation, X-Rite NetProfiler and many others
Aperture: 1.5 mm, 2 mm, 4 mm or 6 mm
Battery: Lithium Ion, 7.4VDC, 2200mAh
Best Match Feature: Yes
Calibration: Automatic on integrated white reference
Color Differences: CIE ∆E* (1976), ∆ECMC, CIE ∆E* (2000), and CIE ∆E* (1994)
Communication Interface: USB 2.0; Bluetooth (optional) - Class II
Connectivity: USB 2.0; Bluetooth
Density Range: 0.0 D – 3.0 D
Density Standards: Status A, E, I, T and G
Dimensions (length, width, height): 18 cm x 7.8 cm x 7.6 cm
7.1" x 3.1" x 3.0"
Embedded NetProfiler Support: Yes
Humidity: 30 to 85% RH (non-condensing)
Illuminants: A, C, D50, D55, D65, D75, F2, F7, F11, F12
Import/Export Format: CxF3
Internal Temperature & Humidity Sensor: 30 to 85% RH (non-condensing)
Light Source: Gas filled tungsten (illuminant type A) and UV LED
Measurement Conditions: M0, M1 (part 1), M1 (part 2) , M2, M3; also available in Xp variant for flexible packaging substrates
Measurement Geometry: 45°/0° ring illumination optics, ISO 5-4:2009(E)
Measurement Time: < 1 sec
NetProfiler Support: Yes
Observers: 2° and 10°
Operating Temperature Range: 10°C to 35°C
50°F to 95°F
Scanning Capability: Yes (Optional Upgrade)
Service Indicator: Certification Reminder
Spectral Analyzer: DRS spectral engine
Spectral Interval: 10 nm
Spectral Range: 400 nm to 700 nm
Spectral Reporting: 400 nm to 700 nm with 10 nm interval
Standards: More than 20'000 standards (incl. data for all M modes); New Color Library Tool to Create and Store Standards
Storage Temperature Range:-20° to 50°C
-4° to 122°F
Weight: 700 g/ 1.6 lbs.
What Included: USB cable, power supply, CD with software and documentation, docking/charging station, quick start guide, carrying case, device certificate
