Operating temperature range: Room temp. +30°C to 260°C
Temperature adjustment accuracy: ±0.5℃
Temperature distribution accuracy: ±2℃（at 200℃）、±2.5℃（at 260℃）
Time to attain max. temp.: Within 45min. from 25°C ->260°C
Temp. decrease time: About 30min. from 260°C ->50°C
Air supply/exhaust damper: Front operation/manual damper Air supply pipe/exhaust pipe at the rear NSSC180 With exhaust duct
Interior/exterior: Stainless steel plate/chrome free electro galvanized steel plate Chemical proof baking finish
Heater and heat insulator: SUS pipe heater & glass wool
Heater capacity: 200 to 220V 2.6 to 3.15kW
Blower fan: Sirocco fan×1
Fan motor: Condenser type motor × 1pc
Cable port: I.D.: 30mm One at the right side of the main body
Door packing: Fluororubber
Air supply portBottom of heater room (Open/Close with a manual damper)
Damper control: Linked air supply / Exhaust with manual knob on the front of the main body
Exhaust port: Upper part of rear of the main body: φ80 (Open / Close with a manual damper)
Heater controlSSR control
Sensor: K-thermocouple (for temp. adjustment, Indivisual overheating prevesion)
Safety unit: Self diagnostic function (Temperature sensor error, Heater disconnection, SSR short-circuit, Automatic overheat prevention function), Key lock,
Safety unit: Program lock, Overheat preventive device, Over current electric leakage breaker, Door switch, Temperature fuse, External alarm terminal
Internal dimensions（W×D×H mm）: 600×500×500mm
External dimensions（W×D×H mm）: 770×696×985mm
Withstand load of shelf: 15 kg / pc.
Shelf support step number: 7 steps
Shelf support pitch: 60mm
Accessories Shelf: 2 pcs.
Accessories Shelf support: 4 pcs.
Power Source: AC200 to 220V 13.5-15A
Weight: 110kg
Remarks(dimensions): 150L
