Number of channel: 1
Device type: Advanced type (-T6)
Frequency band: C-band
Frequency (Wavelength) range: 196.25 to 191.50 THz (1527.60 to 1565.50 nm)
Grid spacing: 100 GHz, 50 GHz, 25 GHz and Manual (min. 0.1 GHz)
Frequency (Wavelength) setting resolution: 0.1 GHz (0.8 pm@1550 nm)
Frequency (Wavelength) fine turning range: ±6 GHz (typ.) (±48 pm@1550 nm)
Frequency (Wavelength) fine turning resolution: 1 MHz (typ.) (8 fm@1550 nm)
Absolute frequency (wavelength) accuracy: ±2.5 GHz (±20 pm@1550 nm)
Frequency (Wavelength) stability 24hours: ±0.3 GHz (2.4 pm@1550 nm)
Frequency (Wavelength) tuning time30 sec. or less
Optical output: +12.5 dBm or more
Attenuation range: 6 dB (resolution: 0.01 dB)
Output level stability: ±0.03 dB (
Spectral linewidth: 100 kHz
SMSR: 45 dB
RIN: –145 dB/Hz
Fiber type: PANDA PMF, Slow axis, in line with connector key Optical connector: Select any of FC/PC or FC/Angled PC *9 Dimensions Approx. 31(W) × 117(H) × 321.5(D) mm, 1-slot wide (excluding protrusions)
Weight: Approx. 0.8 kg
