Port configuration: 1 × 4, 1 × 8
Number of switch: 1
Wavelength: 850 nm/1310 nm, 1310 nm/1550 nm
Insertion loss: 1.0 dB
Repeatability: ±0.01 dB or less
Crosstalk: 60 dB or more, 50 dB or more
Optical return loss: 45 dB or more, 20 dB or more
Maximum input power: +23 dBm
Polarization dependence: 0.08 dBp-p or less
Applicable optical fiber: SMF (ITU-T G.652); Select any of MMF (GI 50/125) (ITU-T G651.1) or MMF (GI 62.5/125) (IEC 60793-2)
Optical connector: Select any of FC/PC or SC/PC
Dimensions: Approx. 31(W) × 117(H) × 321.5(D) mm, 1 slot wide (excluding protrusions)
Weight: Approx. 0.8 kg
