YOKOGAWA CL220 Clamp meter (AC/DC 300A)

Diameter of measurable : 24mm

AC Current Frequency : 20Hz đến 1kHz

* AC Current Range : 40/300A

Resolution : 0.01A

Accuracy :

- 40A : +/- 1.0%rdg+4dgt (50/60Hz), +/- 2.5%rdg+4dgt (20～1kHz)

- 20～200A : +/- 1.5%rdg+4dgt (50/60Hz), +/- 2.5%rdg+4dgt (20～1kHz)

- 200～300A : +/- 3.5%rdg+4dgt (50/60Hz), +/- 4.0%rdg+4dgt (20～1kHz)

* DC Current Range : 40/300A

Resolution : 0.01A

Accuracy :

- 40A : +/- 1.0%rdg+4dgt

- 20～200A : +/- 1.5%rdg+4dgt

- 200～300A : +/- 3.0%rdg

Response Time : Approx. 2 second

Range Switching

Operating temperature and humidity : 0 - 40°C, 90% RH or less (no condensation)

Safety Standard : Conforms EN61010-1, EN61010-2-031, EN61010-2-032

Power Supply : LR-44 x 2 (3V) or SR-44 x 2

Dimensions : Approx. 59 (W) x 147 (H) x 25 (D) mm

Weight : Approx. 100 g
