Capacity (optional): 50N, 100N, 250N 500N, 1KN, 2.5kN, 5KN
Unit (Switchable): N, KN, kgf, Lbf, MPa, Lbf/In, kgf/mm
Precision Grade of Machine:0.5 Level/1 Level
Load Resolution: 1/500,000 (0.5 Level)/ 1/250,000 (1 Level)
Load Magnifying Rate: Section-less
MaxStroke (Exclude the Grips): 650 mm (Standard) 850 mm (Heighten)(Optional)
Test Speed: 0.001-500 mm/min or others
Speed Accuracy: ±0.5%
Displacement Resolution: 0.0004mm
Software: Spring test special software
Motor: Servo motor
Transmission Rod: High accuracy of ball screw
Main Unit Dimension(WxDxH): Standard: 585x505x1290 mm
Power: AC220/50Hz 10A or specified by user
