Pitch: 1.27 mm (0.05 in)
Application: Wire-to-Board
Row Spacing: 2.54 mm (0.1 in)
Unit Weight: 739.229 mg
Housing Color: Black
Latching Type: Eject Latch
Contact Gender: Pin (Male)
Current Rating: 750 mA
Mounting Angle: Straight
Mounting Style: Board Lock
Number of Rows: 2 Row
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: Solder
Mating Post Length: 3.56 mm (0.14 in)
Flammability Rating: UL 94 V-0
Number of Positions: 68 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
