General Specification
Display: Colorful Screen, 3.5 inch
Interface: 1xUSB, 1xOTDR, 1xVFL, 1xOPM, 1xCharging Port 1xRJ45 Port, 1x Memory Card Port
Power Supply: 100V(ac) to 240V(ac), 50~60Hz; Battery: 4000mAH Lithium battery; Operating Time: 12hours, Telcordia GR-196-CORE
Power Saving: Backlight: 0% to 100%, Auto off: 10 to 60mins
Language: English in Default
Environmental Conditions: Operating temperature and humidity: -10℃~+50℃, ≤95% (non-condensation); Storage temperature and humidity: -20℃~+75℃, ≤95% (non-condensation)
OTDR Module
Pulse Width: 3ns to 10us
Distance Range: Max. 64km
Sampling Resolution: Minimum 16cm
Sampling Point: Maximum 65,000
Linearity: ≤0.05dB/dB
Averaging Time: 5s, 15s, 30s, 60s, 120s, 180s
Distance Resolution: 0.001m
Units: km
Event/Attenuation Dead Zone: 3/8m
Dynamic Range: 24/22dB
VFL Module (Visual Fault Locator)
Wavelength (±20nm): 650nm
Power: 10mw, CLASSIII B
Range: 12km
OPM Module (Optical Power Meter)
Wavelength: 850/1300/1310/1490/1550/1625nm
Test Range: -50~+ 26dBm
OLS Module (Optical Laser Source)
Working Wavelength: 1310/1550nm
Output Power: -5dBm
Modulation Frequency: 270Hz, 330Hz, 1kHz, 2kHz
