Output Type: CMOS
Sensitivity: 3.3 mT
With Switch: Without Switch
Mounting Style: SMD/SMT
Output Voltage: 200 mV
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.6 V
Maximum Output Current: 1 mA
Pd - Power Dissipation: 300 mW
Operating Point Min/Max: - 4.7 mT to - 2.3 mT, 2.3 mT to 4.7 mT
Operating Supply Current: 2 uA
Operating Supply Voltage: 1.85 V
Release Point Min/Max (Brp): - 3.4 mT to - 1.2 mT, 1.2 mT to 3.14 mT
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
