Measurement Parameters: ESR, DCV
Basic Accuracy: Internal resistance Ω: 0.5%; Voltage V: 0.1%
Test Range: Internal resistance Ω: 10U / 3.2KΩ; Voltage: 1mV~60V
Screen: Four-color VFD display
Maximum Display Value: Internal resistance Ω: 32000; Voltage V: 60000
Calibration: Full range short circuit zero calibration; REL function
Comparator: 30 sets of data recording, ng-lo, gd-in, ng-hi display and output, adjustable buzzer volume
Trigger Mode: Internal/manual
Interface: RS-232C / RS-485
Power Supply: Voltage 198VAC ~ 240VAC; Frequency 47Hz ~ 63Hz; Power Max 15VA
Dimensions & Weight: Size 385mm(L) × 249mm(W) × 102mm(D); Weight 3.5kg
Accessories: HK3500-A Kelvin test line, HK3800 RS232C interface cable
Options: HK3500-B test probe
Others: Internal resistance Ω: 10U / 3.2KΩ; Voltage 1mV~60V
Features
●Using the vector measurement method, multiple parameters can be measured at the same time
●High-speed, high-precision measurement, the basic accuracy of internal resistance test is 0.5%, the basic accuracy of voltage test is 0.1%, and the fastest test speed can reach 25 times per second
●Comparator (sorting) function, built-in 30 sets of comparator data
●Test line damage detection indication
●Adjustable sound size and brightness
●Compatible with SCPI commands and Modbus commands
●Low power test, maximum test current <100mA
