Output Voltage: 72Vdc
Minimum Load: 0A
Maximum Load: 41.7A
Trim Range (±25%): 54 - 96Vdc
Vprog Adjustment Range (20% to 125%Vo)1: 14.4V - 96Vdc
Adjustment Range:
+ Maximum Load: 14.4 - 72Vdc
+ Max Power (3000W): 72 - 96Vdc
SPECIAL FEATURES
- 3000 watts output power
- Low cost
- 2.5” x 7.0” x 10.9”
- 15.7 watts per cubic inch
- Industrial/medical safety
- -40 ℃ to 70℃ with derating
- 5 Vdc @ 2 A Housekeeping
- High efficiency: 90% typical
- Variable speed “smart fans”
- DSP controlled
- Conformal coat option
- ±25% adjustment range; Up to +33% on LCM30007-T
- V-Programming from 20% to 125%; Up to 133% on LCM30007-T
- VAR configurable to any voltage from a single unit
- Semi F47 compliance at high line
- Five-year warranty
- Supports redundant operation
COMPLIANCE
- EMI Class A, with 6db margin
- EN61000 Immunity
- RoHS3
SAFETY
- UL/cUL Recognized
- ITE(UL/CSA62368-1)
- ANSI/AAMI ES60601-1L
- TUV-SuD ITE + Medical
- CE LVD (EN62368-1 + ROHS)
- UKCA Mark
- CB Report
through Demko for IEC60950-1
through TUV-SuD for IEC60601-1
through DEMKO for IEC62368-1
