- Temperature Ranges: 200 ~ 800°C
- Filter: 4.8 ~ 5.2 µm
- Measurement Accuracy: ±2°C or 2% of reading
- Image Update Rate:
Standard: 60 Hz
E series: 9 Hz
- A/D Resolution: 16 bit
- Detector: 320 x 240 Uncooled Focal Plane Array
- Emissivity Correction: 0.1 ~ 1.0
- Sensitivity/NETD: 0.06°C @ 30°C (0.108°F @ 86°F)
- Focus Range: 30 cm ~ ∞
- Field of View (FOV):
Wide: 53° (H) x 40° (V)
Remote Focus
Interface:
- Analog: TV Output (NTSC or PAL)
- Digital: Gigabit Ethernet
- Connections: 4-pin power (LEMO-0K), RJ45 Ethernet, 3-pin trigger (M8), coaxial (BNC)
Environmental:
- Operating Temperature: 0 ~ 50°C (32 ~ 122°F ) (at housing)
- Storage Temperature: -20 ~ 70°C (-4 ~ 158°F)
- Weight: 1 kg (2.55 lbs) (excludes any protective housing or optional lenses)
- Dimensions: 83 mm x 81.49 mm x 178.28 mm (3.26" x 3.20" x 7.01")
Electrical:
- Power Supply: 12 ~ 30V or Power over Ethernet standards
- Power Consumption: 10 W Typical, 13 W Max
- Load (Analog Output): 75 Ω
- Scope of delivery: 2 m Ethernet cable, 2 m power supply cable, power supply unit (100 ~ 240 VAC, 47 ~ 63 Hz), lens cap, manual (on CD), quick start guide, carrying case, and LumaSpec RT Viewer software.
