Advanced Energy MDX 1.5kW DC Power System (750V, 1500W)
Manufacturer: Advanced Energy Model: MDX 1.5kW Guarantee: 12 Month - Request a Quotation
- Request a Quotation
- Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
- Regulation: 0.2%
- Ripple: 5% at 50 kHz
- Ramp Timer: 1 ~ 10 sec or 1 ~ 10 min
- Power Output: 1500W
- Output Voltage: 500 V, 750 V
- Ignition Voltage: 800 V, 1200 V
- Input Power: 208/220 VAC, 50/60 Hz ±10%, 13.4 A
- Power Factor: 0.6
- Dimension: 175.3 mm (H) x 266.7 mm (W) x 400 mm (D); 6.9" (H) x 10.5" (W) x 15.75" (D)
- Weight: 8.6 kg (19 lb)
- Ambient Operating Temperature: 0 ~ 40°C (32 ~ 104°F); max value of average over 24 h: 35°C (95°F)
- Coolant Type: Air (gas)
- Coolant Temperature: 0 ~ 35°C (32 ~ 95°F)
- Humidity: 15 ~ 85% relative humidity, no condensing or icing
- Atmospheric Pressure: 800 mbar min (approx. 2000 m above sea level)
