Accuracy class: ISO 376 : 1
Nominal Load : 3MN
Relative Errors (At Reading):
a) repeatability 0°-120°-240° (b): ≤ ±0.145%
b) interpolation (fc): ≤ ±0.090%
c) reversibility (u): ≤ ±0.240%
d) zero (fo): ≤ ±0.030% F.S.
Linearity: ≤ ±0.05% F.S.
Hysteresis: ≤ ±0.05% F.S.
Temperature Effect (10°C):
a) on zero: ≤ ±0.028% F.S.
b) on sensitivity: ≤ ±0.024% F.S.
Nominal Sensitivity: 2mV/V
Sensivity Tolerance: ≤ ±0.1% F.S
Nominal Load:
Input Resistance: 350 ± 2Ω
Output Resistance: 350 ± 2Ω
Insulation Resistance: > 5 GΩ
Zero Balance: ≤ ± 1% F.S.
Recomended Supply Voltage: 10 V
Nominal Supply Voltage Range: 1-15 V
Maximum Supply Voltage: 18 V
Mechanical Limit Values Referred To Nominal Load::
a) service load: 120%
b) max permissible load: 150%
c) breaking load: >300%
d) max transverse load: 100%
e) max permissible dynamic load: 50%
Reference Temperature: +23°C
Temperature Nominal Range: -10 / +40 °C
Service Temperature: -10 / +70 °C
Storage Temperature: -20 / +80 °C
Weight (Kg) : ~15KG
Protection Class (En 60529): IP65
Execution Material: Acciaio Inox / Stainless Steel
Connector Type: MIL-C-5015 7 poles male
