Nominal Load : 10kN
Nominal Sensitivity: 2 mV/V
Calibration Tolerance: ≤ ± 0.1 % F.S.
Temperature Effect (10 °C):
a) on zero: ≤ ± 0.028 % F.S.
b) on sensitivity: ≤ ± 0.024 % F.S.
Linearity: ≤ ±0.05% F.S.
Hysteresis: ≤ ±0.05% F.S.
Repeatability: ≤ ±0.01% F.S.
Input Resistance: 800 ± 20 Ω
Output Resistance: 705 ± 2 Ω
Insulation Resistance: > 5 GΩ
Zero Balance: ≤ ± 1 % F.S.
Recommended Supply Voltage: 10 V
Nominal Supply Voltage: 1 - 15 V
Maximum Supply Voltage: 18 V
Natural Frequency: ~ 9 Khz
Mechanical Limit Values::
a) service load: 120 % F.S.
b) max permissible load: 150 % F.S.
c) breaking load: >300 % F.S.
d) max transverse load: 100 % F.S.
e) max permissible dynamic load: 75 % F.S.
Displacement At Nominal Load: ~ 0.06 mm
Reference Temperature: +23 °C
Temperature Nominal Range: -10 / +40 °C
Service Temperature: -20 / +70 °C
Storage Temperature: -20 / +80 °C
Weight: ~ 0.28 kg
Protection Class (En 60529): IP67
Execution Material: Stainless Steel
Connector Output: M12 5 Poles Male connector
Fixing Screws:
a) diameter: M5
b) resistance class: 12.9
c) tightening torque: 8 Nm
