Input: 3-phase 3-wire +PE，340V~420VAC，47-63Hz
Output: Voltage 0～1000V
Current 0～30A
Power 0～10kW
Testing accuracy: Voltage ≤0.15%Umax，Resolution 0.01V（＞1000V，0.1V）
Current ≤0.3%Imax，Resolution 0.01A
Power ≤1%Pmax，Resolution 0.001kW（＞100kW，0.01kW）
Ripple and Noise
20Hz~20MHz
Vrms 350mV
Vpp 1600mV
Load effect: Voltage≤0.05%Umax，Current≤0.15%Imax
Source effect: Voltage≤0.02%Umax，Current≤0.05%Imax
Transient response time: ≤2ms
Rise time: 100%50ms（10%-90%）
Max output voltage drop compensation: 25V
Environment: Temperature：0～40℃；Humidity：20～90%RH
Dimension W×H×D（mm）: 440×133×600
Weight: 27kg
Remark: The current range of models above 1000V can be customized for 40A
