Pitch: 3 mm (0.118 in)
Wire Gauge: 30 AWG to 20 AWG, 18 AWG to 16 AWG
Application: Wire-to-Board
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 12.5 A
Mounting Angle: Straight
Mounting Style: Kinked Pin
Number of Rows: 2 Row
Voltage Rating: 250 V
Contact Plating: Tin
Contact Material: Copper Alloy
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 8 Position
Insulation Resistance: 1 GOhms
Termination Post Length: 3.2 mm (0.126 in)
Minimum Operating Temperature: - 40 C
