Amphenol Procom ProEdge B-G1-L2-P5-S/S MIMO 2x5G/4G 617-7200Mhz w/16 Feet LL-195 SMA, 1X GNSS w/16 Feet LL-195 W/ SMA, Black Radome
Manufacturer: Amphenol Procom Model: ProEdge B-G1-L2-P5-S/S - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Gain: 25 dB
VSWR: <2:1, <2:1, <2:1, <2:1, <2.5:1
Style: Mobile Disk
Width: 79 mm
Height: 69 mm
Length: 208.6 mm
IP Rating: IP69
Impedance: 50 Ohms
Cable Type: RG178, RG316
Application: Autonomous Vehicles, Robotics, Smart Cities, Smart Metering, Telematics
Cable Length: 5 m
Polarization: RHCP, Vertical
Power Rating: 25 W
Mounting Style: Stud
Number of Bands: 5 Band
Ground Plane Size: 600 mm x 600 mm
Maximum Frequency: 7.2 GHz
Minimum Frequency: 617 MHz
Termination Style: Connector
Antenna Connector Type: SMA (Male), SMA (Male)
Protocol - GPS, GLONASS: GNSS
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 50 C
Protocol - Cellular, NBIoT, LTE: LTE
