Gender: Jack (Socket)
Polarity: Standard
Impedance: 50 Ohms
Isolation: Non-Isolated
RF Series: BNC
Body Style: Straight
Cable Type: RG-174, 188, 316, Belden 7805
Body Finish: Nickel
Orientation: Straight
Unit Weight: 10.500 g
REACH - SVHC: Details
Body Material: Brass
Mating Cycles: 500
Mounting Style: Bulkhead - Rear Mount
Voltage Rating: 500 V
Contact Plating: Gold
Contact Material: Phosphor Bronze
Maximum Frequency: 4 GHz
Termination Style: Crimp
Coupling Mechanism: Bayonet
Contact Termination: Crimp
Insulation Resistance: 5 GOhms
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 65 C
