Gender: Jack (Socket)
IP Rating: IP67
Impedance: 50 Ohms
Isolation: Non-Isolated
RF Series: 4.3-10
Body Style: Flange
Body Finish: Bronze
Orientation: Straight
Unit Weight: 59.370 g
REACH - SVHC: Details
Body Material: Brass
Mating Cycles: 100 Cycles
Mounting Style: Flange Mount
Voltage Rating: 2.5 kV
Contact Plating: Silver
Contact Material: Beryllium Copper
Maximum Frequency: 6 GHz
Termination Style: Solder Cup
Coupling Mechanism: Threaded
Contact Termination: Solder
Insulation Resistance: 5 GOhms
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 55 C
