Features: CMOS or LVDS SPI Compatible Serial I/O, Four Simultaneously Sampling Channels
Shutdown: No Shutdown
Input Type: Differential/Single-Ended
Resolution: 12 bit
Architecture: SAR
Sampling Rate: 5 MS/s
Interface Type: Serial CMOS, Serial LVDS
Mounting Style: SMD/SMT
Reference Type: External, Internal
Development Kit: DC2395A-I
Reference Voltage: 2.048 V/4.096 V
Number of Channels: 4 Channel
Number of Converters: 4 Converter
Analog Supply Voltage: 3.3 V, 5 V
Pd - Power Dissipation: 214 mW
FPBW - Full Power Bandwidth: 95 MHz
INL - Integral Nonlinearity: 0.5 LSB
SNR - Signal to Noise Ratio: 77.6 dB
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: 0.4 LSB
THD - Total Harmonic Distortion: - 85 dB
SFDR - Spurious Free Dynamic Range: 93 dB
SINAD - Signal to Noise and Distortion Ratio: 76.5 dB
