Analog Devices LTC2688HCB-16#TRPBF SoftSpan DAC 16 Channel 16-Bit +/-15V SoftSpan DACs

Features: SoftSpan DAC Channels

Shutdown: Shutdown

Gain Error: 0.08 % FSR

Resolution: 16 bit

Settling Time: 11 us

Interface Type: SPI

Mounting Style: SMD/SMT

Reference Voltage: 4.096 V

Number of Channels: 16 Channel

Number of Converters: 16 Converters

Supply Voltage - Max: 5.25 V

Supply Voltage - Min: 4.75 V

Analog Supply Voltage: 4.75 V to 5.25 V

Digital Supply Voltage: 1.71 V

Operating Supply Current: 33.6 mA

INL - Integral Nonlinearity: 3 LSB

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

DNL - Differential Nonlinearity: 1 LSB
