Gain: 29 dB
Technology: GaAs
Mounting Style: SMD/SMT
Test Frequency: 9 GHz to 17 GHz
Input Return Loss: 16 dB
NF - Noise Figure: 7 dB
Number of Channels: 1 Channel
Operating Frequency: 5 GHz to 17 GHz
Pd - Power Dissipation: 1.06 W
Operating Supply Current: 180 mA
Operating Supply Voltage: 5 V
P1dB - Compression Point: 23 dBm
OIP3 - Third Order Intercept: 30 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
