Gain: 14 dB
Technology: GaAs
Unit Weight: 15.089 g
Mounting Style: SMD/SMT
Test Frequency: 18 GHz to 22 GHz
Input Return Loss: 15 dB
NF - Noise Figure: 3 dB
Number of Channels: 1 Channel
Operating Frequency: 0 Hz to 22 GHz
Supply Voltage - Max: 15 V
Supply Voltage - Min: 10 V
Pd - Power Dissipation: 2 W
Operating Supply Current: 500 mA
Operating Supply Voltage: 10 V to 15 V
P1dB - Compression Point: 31.5 dBm
OIP3 - Third Order Intercept: 41.5 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
