Input
Input range: 90 - 264 Vac; 164 - 320 Vdc
Frequency: 47 Hz to 63 Hz
Max input current: 8.0 A rms @ 90 Vac
Output
Main DC Output:
Nominal setting (12 V / 1 A, 12 VSB / 0.1 A): MIN: 12.05/ NOM: 12.15/ MAX: 12.25
Total output regulation range： MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 1/ MAX: 45 A
Standby DC Output:
Nominal setting (12 V / 1 A, 12 VSB / 0.1 A): MIN: 12.05/ NOM: 12.2/ MAX: 12.35
Total output regulation range: MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 0/ MAX: 2.5 A
Operating temperature: 0 to 50 °C, the maximum operating temperature (50 °C) is to be derated by 1 °C per 300 m above 2000 m
Operating humidity: +5% to +85% non-condensing
Airflow: Reverse fan
Nominal Output Voltage: 12.0 Vdc
Set Point: 11.9 - 12.1 Vdc
Regulation Band: 11.4 - 12.6 Vdc
Minimum Current: 1 A
Maximum Current: 45 A
Output Ripple P/P: 120 mV
Standby: 12.0 V @ 2.5 A
