AI Accelerator: NVIDIA® Jetson Nano™
CPU: Quad-core ARM® Cortex®-A57 MPCore processor
GPU: 128-core NVIDIA Maxwell™ GPU
Chipset: SoC integrated
System Memory: 4GB 64-bit LPDDR4 onboard
COM: N/A
USB :
1 x USB 3.1 Gen1
1 x USB 2.0
1 x Micro USB for image flash
Ethernet/PoE:
1 x 10/100/1000 Mbps Ethernet (Via Jetson Nano™)
1 x 10/100/1000 Mbps PoE (Intel® I210-IT; max. up to 15W)
Display: 1 x HDMI 2.0 with 4K2K supported
Digital I/O: N/A
Audio: N/A
Storage:
Onboard 16GB eMMC (via Jetson Nano™)
1 x M.2 Key M 2280 with PCIe x4 NVMe SSD slot
1 x Micro SD slot
Expansion:
1 x Full-size PCI Express Mini Card slot (USB + PCI Express signal)
1 x SIM slot
Others
1 x Recovery switch
1 x Reset button
1 x Power button
1 x 12 VDC power input connector
2 x SMA-type antenna connector
Power Supply: 12 VDC screw type
Watchdog Timer: Built-in Nano
Construction: Aluminum extrusion and heavy-duty steel, IP40
Operating Temperature: -30°C to +60°C (-22°F to +140°F)
Relative Humidity: 10% - 95%, non-condensing
Vibration: 3 Grms with M.2 (5 to 500Hz, X, Y, Z directions)
Dimensions (W x D x H): 148.6 x 129.8 x 34.6 mm (5.85" x 5.11" x 1.36")
Weight (net/gross): 1 kg (2.20lb)/1.6 kg (3.52lb)
Certifications: CE, FCC Class A
EOS Support: Linux Ubuntu 18.04
Mounting:
Wall mount kit
DIN-rail kit
VESA mount kit
