Resolution (H x V Pixels): 1280 x 1024
Resolution: 1.3 MP
Sensor Type: onsemi / PYTHON NOIP1SE1300A / Progressive scan CMOS / Global shutter
Sensor Format: 1/2 inch
Effective Sensor Diagonal: 7.9 mm
Pixel Size (H x V): 4.8 x 4.8 μm
Frame Rate (at Default Settings): 88 fps (at fast sensor readout mode) / 81fps (at normal sensor readout mode)
Mono / Color: Mono
Image Data Interface: Fast Ethernet (100 Mbit/s) Gigabit Ethernet (1000 Mbit/s)
Synchronization: Via hardware trigger / Via software trigger / Via free run
Exposure Time Control: Via hardware trigger / Programmable via the camera API
Camera Power Requirements: ≈3.1 W (typical) /≈3.3 W (max.) when using Power over Ethernet / ≈2.7 W (typical) / ≈2.9 W (max.) @ 12–24 VDC when supplied via I/O connector
I/O Lines: 1 opto-coupled input line / 1 opto-coupled output line / 1 general purpose I/O (GPIO) line
Lens Mount: C-mount
Size (L x W x H): 42.0 x 29 x 29 mm (without lens mount or connectors) / 60.3 x 29 x 29 mm (with lens mount and connectors)
Weight: <90 g
