Resolution (H x V Pixels): 1920 x 1080
Resolution: 2 MP
Sensor Type: onsemi MT9P031 / Progressive scan CMOS / Rolling shutter
Sensor Format: 1/3.7 inch
Effective Sensor Diagonal: 4.85 mm
Pixel Size (H x V): 2.2 x 2.2 μm
Frame Rate (at Default Settings): 25 fps
Mono / Color: Color
Image Data Interface: Fast Ethernet (100 Mbit/s) Gigabit Ethernet (1000 Mbit/s)
Synchronization: Via hardware trigger / Via software trigger / Via free run
Exposure Time Control: Via hardware trigger / Programmable via the camera API
Camera Power Requirements: ≈2.7 W when using Power over Ethernet / ≈2.2 W @ 12 VDC when supplied via I/O connector
I/O Lines: 1 opto-coupled input line / 1 opto-coupled output line
Lens Mount: C-mount
Size (L x W x H): 42.0 x 29 x 29 mm (without lens mount or connectors) / 60.3 x 29 x 29 mm (with lens mount and connectors)
Weight: <90 g
