Resolution (H x V Pixels): 1936 x 1216 (full resolution) / 1920 x 1200 (default resolution) / You can change the resolution by changing the image ROI.
Resolution: 2.3 MP
Sensor Type: Sony IMX174LLJ-C / Progressive scan CMOS / Global shutter
Sensor Format: 1/1.2 inch
Effective Sensor Diagonal: 13.4 mm
Pixel Size (H x V): 5.86 x 5.86 μm
Frame Rate (at Default Settings): 50 fps / Higher frame rates are possible if you change the Packet Size to 4000 and the Bandwidth Reserve to 5.
Mono / Color: Mono
Image Data Interface: Fast Ethernet (100 Mbit/s) Gigabit Ethernet (1000 Mbit/s)
Synchronization: Via hardware trigger / Via software trigger / Via free run
Exposure Time Control: Via hardware trigger / Programmable via the camera API
Camera Power Requirements: ≈3.2 W (typical) / ≈3.4 W (max.) when using Power over Ethernet / ≈2.8 W (typical) / ≈3.0 W (max.) @ 12–24 VDC when supplied via I/O connector
I/O Lines: 1 opto-coupled input line / 1 opto-coupled output line / 1 general purpose I/O (GPIO) line
Lens Mount: C-mount
Size (L x W x H): 42.0 x 29 x 29 mm (without lens mount or connectors) / 60.3 x 29 x 29 mm (with lens mount and connectors)
Weight: <90 g
