Resolution (H x V Pixels): 2592 x 2048
Resolution: 5 MP
Sensor Type: onsemi / PYTHON NOIP1SE5000A / Progressive scan CMOS / Global shutter
Sensor Format: 1 inch
Effective Sensor Diagonal: 15.9 mm
Pixel Size (H x V): 4.8 x 4.8 μm
Frame Rate (at Default Settings): 21 fps (at fast sensor readout mode) / 20 fps (at normal sensor readout mode)
Mono / Color: Color
Image Data Interface: Fast Ethernet (100 Mbit/s) Gigabit Ethernet (1000 Mbit/s)
Synchronization: Via hardware trigger / Via software trigger / Via free run
Exposure Time Control: Via hardware trigger / Programmable via the camera API
Camera Power Requirements: ≈3.9 W (typical) / ≈4.1 W (max.) when using Power over Ethernet / ≈3.4 W (typical) / ≈3.6 W (max.) @ 12–24 VDC when supplied via I/O connector
I/O Lines: 1 opto-coupled input line / 1 opto-coupled output line / 1 general purpose I/O (GPIO) line
Lens Mount: C-mount
Size (L x W x H): 42.0 x 29 x 29 mm (without lens mount or connectors) / 60.3 x 29 x 29 mm (with lens mount and connectors)
Weight: <90 g
