Resolution (H x V Pixels): 5120 x 5120 (8-bit pixel format)
Resolution: 25 MP
Sensor Type: Gpixel GMAX0505 / Progressive scan CMOS / Global shutter
Sensor Format: 1.1 inch
Effective Sensor Diagonal: 18.1 mm
Pixel Size (H x V): 2.5 µm x 2.5 µm
Frame Rate (at Default Settings): 150 fps (with pixel format set to Mono 8)
Mono / Color: Color
Image Data Interface: CoaXPress, 4x CXP-12, 2x CXP-12, 1x CXP-12, 4x CXP-6, 2x CXP-6
Synchronization: Via hardware trigger / Via software trigger / Via free run
Exposure Time Control: Via hardware trigger / Programmable via the camera API
Camera Power Requirements: Power over CoaXPress (PoCXP): 24 VDC supplied via the camera\
I/O Lines: 1 galvanic-isolated input line / 1 galvanic-isolated output line
Lens Mount: C-mount
Size (L x W x H): 65 mm x 65 mm x 71 mm
Weight: 400 g (without lens mount)
Conformity: CE (includes RoHS), EAC, UL Listed, FCC, KC, GenICam, CoaXPress 2.0, IP30
Software: Basler pylon Windows (version 6.3 or higher) Basler pylon Linux x86 (64 bit) (version 6.3 or higher)
