Resolution (H x V Pixels): 2592 x 1944
Resolution: 5 MP
Sensor Type: onsemi MT9P031 / Progressive scan CMOS / Rolling shutter
Sensor Format: 1/2.5 inch
Effective Sensor Diagonal: 7.13 mm
Pixel Size (H x V): 2.2 x 2.2 μm
Frame Rate (at Default Settings): 14 fps
Mono / Color: Color
Image Data Interface: USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Synchronization: Via hardware trigger / Via software trigger / Via free run
Exposure Time Control: Programmable via the camera API
Camera Power Requirements: ≈1.3 W (typical) @ 5 VDC
I/O Lines: 2 general purpose I/O (GPIO) lines
Lens Mount: CS mount
Size (L x W x H): 20 x 29 x 29 mm
Weight: <15 g
Conformity: CE (includes RoHS), EAC, UL Listed, GenICam 2.x (including PFNC 1.x and SFNC 2.x), USB3 Vision, REACH, KC
Software: Basler pylon Camera Software Suite (version 4.2 or higher) Available for Windows, Linux x86, Linux ARM, macOS, and Android
