Width: 50.8 mm (2 in)
Height: 30.1 mm (1.185 in)
Length: 76.2 mm (3 in)
Industry: Industrial
Approvals: Class1 SELV, CSA/UL60950-1, EN60950-1, IEC60950-1
Compliance: Class1 SELV, CSA/UL60950-1, EN60950-1, IEC60950-1
Efficiency: 93 %
Output Power: 120 W
Input Voltage: 85 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Power - Convection: 100 W
Power - Forced Air: 120 W
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 2.5 A
Output Voltage-Channel 1: 48 VDC
Operating Temperature Range: - 40 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 40 C
