Frequency Range: 350 MHz to 6 GHz
Power Range: 0.25 W to 500 W
Dynamic Range: 33 dB
Impedance: 50Ω
Insertion VSWR:
1.065 350 to 2000 MHz (max)
1.12, 2000 to 6000 MHz (max)
Insertion Loss: 0.05 dB Max
Connectors: N (Female)
Interface: USB 2.0 Type B (USBTMC)
Power Supply: USB Port
Sample Rate: 44 M Samples/s (max)
Temperature Operating: –10 to +50 °C (+14 to +122 °F)
Storage: –40 to +80 °C (–40 to +176 °F)
Humidity: 95% (max), non-condensing
Dimensions: 5.9 in x 4.8 in x 1.3 in (150 mm x 122 mm x 33 mm)
Weight: 1.5 lbs (max)
