Bourns 3362R-1-101LF 0.25 in Square Trimming Potentiometer 1/4IN SQ 100 OHM 10% 0.5WATTS
Manufacturer: Bourns Model: 3362R-1-101LF - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Height: 4.7 mm
Tolerance: 10 %
Adjustment: Top Cross
Resistance: 100 Ohms
Orientation: Vertical Adjustment
Unit Weight: 570 mg
Element Type: Cermet
Power Rating: 500 mW (1/2 W)
REACH - SVHC: Details
Mounting Style: PCB Mount
Voltage Rating: 300 V
Number of Turns: 1 Turn
Termination Style: PC Pin
Temperature Coefficient: 100 PPM / C
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
