Width: 12.5 mm
Height: 6 mm
Length: 12.5 mm
Core Type: Wirewound
Q Minimum: 29
Shielding: Shielded
Tolerance: 20 %
Inductance: 22 uH
Application: Automotive
Termination: Standard
Unit Weight: 3.671 g
Core Material: Ferrite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 2.52 MHz
Termination Style: SMD/SMT
Maximum DC Current: 3.7 A
Saturation Current: 3.7 A
Maximum DC Resistance: 43 mOhms
Self Resonant Frequency: 13.4 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
