CAS CI-605A Weighing Controller

Load cell excitation voltage: DC 5V

Load cell connection: 10 EA (350Ω)

Load cell input range: -2.0 mV/V~3.0 mV/V

Input Sensitivity: 0.5 ㎶/D (Approval), 0.3 ㎶/D (NonApproval)

A/D Internal resolution: 1/520,000

A/D Display resolution: 1/10,000 (OIML /NTEP/KS), 1/20,000 (Non approval)

A/D Conversion speed: 200 time/sec

A/D conversion method: Sigma-delta

Display: 4.3" TFT Color LCD

Key: Numeric Key 10, Function Key 9

Interface

Standard: RS232 (COM1, COM2)

Option: RS422, RS485, Analog_out /BCD_out

External I/O: Input 4 /Output 6

Power AC: AC 100 ~240V 50/60Hz

Operating Temp: -10˚C ~40˚C

Approval: OIML, CE

Dimensions (W x D x H) mm: 192.9 x 190.2 x 98.4

Weight (kg): 1.5
